FF109减速机铭牌参数说明解读含义:有关型号描述的详细情况及其他信息可以参阅本业附件下载中的FF109减速机选型样本。
FF109-YVPEJ4KW-4P-146.49-M5-270°
FF:系列代号
109:减速机规格代号
Y:电机
VPEJ:变频刹车电机
4KW:电机功率
4P:电机级数
146.49:减速机传动比
M5:减速机安装位置
270°:接线盒位置
FF109减速机润滑油型号:
FF109减速机润滑油加注量,具体值根据级数与传动比的不同而各异。请您在加注润滑油时一定注意油位螺栓所指示的精确油量。本页附件中的FF109减速机选型样本中列出了安装位置从M1到M6FF109减速机相应的润滑油加注标准,请自行下载查看。平行轴斜齿轮减速机
FF109减速机某些安装位置发生搅油损失的机会较高。出现下列情况时请与BOSERL公司进行联系:若无特殊规定,BOSERL公司发货时会根据FF109减速机的安装位置给驱动装置加润滑油,因此应在订货时指定安装位置(M1…M6,参见“FF109减速机说明书中的安装位置与订货说明”章节)。若之后对安装位置需要改动,则加润滑油必须与安装位置相符(润滑油加注量)。
FF109减速机特殊应用场合必须使用特殊润滑油,比如要求长使用寿命润滑油。若需要可提供用于食品行业和生物降解润滑油。齿轮减速电机
FF109减速机推荐使用的润滑油,其等级和粘度指标见下表:
ISO标准润滑油 | 粘贴指标 | 环境温度°C | 减速机型号 |
MINERALOILCLP(cc) | ISOVG220 | -10-+40 | R系列、F系列、K系列减速机 |
ISOVG680 | 0-+40 | S系列减速机 |
ISO标准润滑油 | 粘贴指标 | 环境温度°C | 减速机型号 |
MINERALOILCLP(cc) | ISOVG100 | -20-+25 | R系列、F系列、K系列减速机 |
Synthetic fluid,clp pg | ISOVG220 | -25-+80 | R系列、F系列、K系列减速机 |
Synthetic fluid,CLP HC | ISOVG460 | -30-+80 | S系列减速机 |
FF109减速机使用说明:
FF109减速机危险使用说明:驱动装置意外启动会造成挤伤,可能造成重伤或死亡;开始工作前,应先断开减速电机的电源并且采取措施防止意外接通!
FF109减速机警告说明:由于FF109减速机发热或FF109减速机油温过高可能引起烫伤;对FF29减速机进行操作前先冷却;拧出油位检查螺栓和放油螺栓时要格外小心。
FF109减速机注意事项:若未注入正确的FF109减速机油则可能造成润滑油性能失效,可能造成财产损失;合成润滑油不可能相互混用并不可与矿物润滑油混用;矿物油用作标准的润滑油,不能用于特殊行业。
FF109减速机提示事项:油位检查螺栓、放油螺栓、以及透气阀的位置在安装位置上,要参见FF109减速机说明书安装位置章节中的内容。刹车电机减速机
FF109减速机的螺母:立式安装FF109减速机输出法兰螺母规格M16;FF109减速机螺母/螺母拧紧扭矩强度等级10.9。
FF109减速机型号:
NFF107-Y1.5KW,NFF107-Y100M4,NFF107-Y112M4,NFF107-Y11KW,NFF107-Y132M4,NFF107-Y15KW,NFF107-Y160M4,NFF107-Y18.5KW,NFF107-Y180M4,NFF107-Y2.2KW,NFF107-Y200M4,NFF107-Y225M4,NFF107-Y22KW,NFF107-Y30KW,NFF107-Y37KW,NFF107-Y3KW,NFF107-Y45KW,NFF107-Y4KW,NFF107-Y5.5KW,NFF107-Y7.5KW,NFF107-Y80M4,NFF107-Y90M4,NFF107-YB100M4,NFF107-YB112M4,NFF107-YB132M4,NFF107-YB160M4,NFF107-YB180M4,NFF107-YB200M4,NFF107-YB225M4,NFF107-YB80M4,NFF107-YB90M4,NFF107-YDP100M4,NFF107-YDP112M4,NFF107-YDP132M4,NFF107-YDP160M4,NFF107-YDP180M4,NFF107-YDP200M4,NFF107-YDP225M4,NFF107-YDP80M4,NFF107-YDP90M4,NFF107-YE100M4,NFF107-YE112M4,NFF107-YE132M4,NFF107-YE160M4,NFF107-YE180M4,NFF107-YE200M4,NFF107-YE225M4,NFF107-YE80M4,NFF107-YE90M4,NFF107-YEJ100M4,NFF107-YEJ112M4,NFF107-YEJ132M4,NFF107-YEJ160M4,NFF107-YEJ180M4,NFF107-YEJ200M4,NFF107-YEJ225M4,NFF107-YEJ80M4,NFF107-YEJ90M4,NFF107-YEJB100M4,NFF107-YEJB112M4,NFF107-YEJB132M4,NFF107-YEJB160M4,NFF107-YEJB180M4,NFF107-YEJB200M4,NFF107-YEJB225M4,NFF107-YEJB80M4,NFF107-YEJB90M4,NFF107-YP100M4,NFF107-YP112M4,NFF107-YP132M4,NFF107-YP160M4,NFF107-YP180M4,NFF107-YP200M4,NFF107-YP225M4,NFF107-YP80M4,NFF107-YP90M4,NFF107-YPB100M4,NFF107-YPB112M4,NFF107-YPB132M4,NFF107-YPB160M4,NFF107-YPB180M4,NFF107-YPB200M4,NFF107-YPB225M4,NFF107-YPB80M4,NFF107-YPB90M4,NFF107-YPE100M4,NFF107-YPE112M4,NFF107-YPE132M4,NFF107-YPE160M4,NFF107-YPE180M4,NFF107-YPE200M4,NFF107-YPE225M4,NFF107-YPE80M4,NFF107-YPE90M4,NFF107-YS100M4,NFF107-YS112M4,NFF107-YS132M4,NFF107-YS160M4,NFF107-YS180M4,NFF107-YS200M4,NFF107-YS225M4,NFF107-YS80M4,NFF107-YS90M4,NFF107-YVB100M4,NFF107-YVB112M4,NFF107-YVB132M4,NFF107-YVB160M4,NFF107-YVB180M4,NFF107-YVB200M4,NFF107-YVB225M4,NFF107-YVB80M4,NFF107-YVB90M4,NFF107-YVP100M4,NFF107-YVP112M4,NFF107-YVP132M4,NFF107-YVP160M4,NFF107-YVP180M4,NFF107-YVP200M4,NFF107-YVP225M4,NFF107-YVP80M4,NFF107-YVP90M4,NFF107-YVPEJ100M4,NFF107-YVPEJ112M4,NFF107-YVPEJ132M4,NFF107-YVPEJ160M4,NFF107-YVPEJ180M4,NFF107-YVPEJ200M4,NFF107-YVPEJ225M4,NFF107-YVPEJ80M4,NFF107-YVPEJ90M4,SFF107-Y1.5KW,SFF107-Y100M4,SFF107-Y112M4,SFF107-Y11KW,SFF107-Y132M4,SFF107-Y15KW,SFF107-Y160M4,SFF107-Y18.5KW,SFF107-Y180M4,SFF107-Y2.2KW,SFF107-Y200M4,SFF107-Y225M4,SFF107-Y22KW,SFF107-Y30KW,SFF107-Y37KW,SFF107-Y3KW,SFF107-Y45KW,SFF107-Y4KW,SFF107-Y5.5KW,SFF107-Y7.5KW,SFF107-Y80M4,SFF107-Y90M4,SFF107-YB100M4,SFF107-YB112M4,SFF107-YB132M4,SFF107-YB160M4,SFF107-YB180M4,SFF107-YB200M4,SFF107-YB225M4,SFF107-YB80M4,SFF107-YB90M4,SFF107-YDP100M4,SFF107-YDP112M4,SFF107-YDP132M4,SFF107-YDP160M4,SFF107-YDP180M4,SFF107-YDP200M4,SFF107-YDP225M4,SFF107-YDP80M4,SFF107-YDP90M4,SFF107-YE100M4,SFF107-YE112M4,SFF107-YE132M4,SFF107-YE160M4,SFF107-YE180M4,SFF107-YE200M4,SFF107-YE225M4,SFF107-YE80M4,SFF107-YE90M4,SFF107-YEJ100M4,SFF107-YEJ112M4,SFF107-YEJ132M4,SFF107-YEJ160M4,SFF107-YEJ180M4,SFF107-YEJ200M4,SFF107-YEJ225M4,SFF107-YEJ80M4,SFF107-YEJ90M4,SFF107-YEJB100M4,SFF107-YEJB112M4,SFF107-YEJB132M4,SFF107-YEJB160M4,SFF107-YEJB180M4,SFF107-YEJB200M4,SFF107-YEJB225M4,SFF107-YEJB80M4,SFF107-YEJB90M4,SFF107-YP100M4,SFF107-YP112M4,SFF107-YP132M4,SFF107-YP160M4,SFF107-YP180M4,SFF107-YP200M4,SFF107-YP225M4,SFF107-YP80M4,SFF107-YP90M4,SFF107-YPB100M4,SFF107-YPB112M4,SFF107-YPB132M4,SFF107-YPB160M4,SFF107-YPB180M4,SFF107-YPB200M4,SFF107-YPB225M4,SFF107-YPB80M4,SFF107-YPB90M4,SFF107-YPE100M4,SFF107-YPE112M4,SFF107-YPE132M4,SFF107-YPE160M4,SFF107-YPE180M4,SFF107-YPE200M4,SFF107-YPE225M4,SFF107-YPE80M4,SFF107-YPE90M4,SFF107-YS100M4,SFF107-YS112M4,SFF107-YS132M4,SFF107-YS160M4,SFF107-YS180M4,SFF107-YS200M4,SFF107-YS225M4,SFF107-YS80M4,SFF107-YS90M4,SFF107-YVB100M4,SFF107-YVB112M4,SFF107-YVB132M4,SFF107-YVB160M4,SFF107-YVB180M4,SFF107-YVB200M4,SFF107-YVB225M4,SFF107-YVB80M4,SFF107-YVB90M4,SFF107-YVP100M4,SFF107-YVP112M4,SFF107-YVP132M4,SFF107-YVP160M4,SFF107-YVP180M4,SFF107-YVP200M4,SFF107-YVP225M4,SFF107-YVP80M4,SFF107-YVP90M4,SFF107-YVPEJ100M4,SFF107-YVPEJ112M4,SFF107-YVPEJ132M4,SFF107-YVPEJ160M4,SFF107-YVPEJ180M4,SFF107-YVPEJ200M4,SFF107-YVPEJ225M4,SFF107-YVPEJ80M4,SFF107-YVPEJ90M4,WFF107-Y1.5KW,WFF107-Y100M4,WFF107-Y112M4,WFF107-Y11KW,WFF107-Y132M4,WFF107-Y15KW,WFF107-Y160M4,WFF107-Y18.5KW,WFF107-Y180M4,WFF107-Y2.2KW,WFF107-Y200M4,WFF107-Y225M4,WFF107-Y22KW,WFF107-Y30KW,WFF107-Y37KW,WFF107-Y3KW,WFF107-Y45KW,WFF107-Y4KW,WFF107-Y5.5KW,WFF107-Y7.5KW,WFF107-Y80M4,WFF107-Y90M4,WFF107-YB100M4,WFF107-YB112M4,WFF107-YB132M4,WFF107-YB160M4,WFF107-YB180M4,WFF107-YB200M4,WFF107-YB225M4,WFF107-YB80M4,WFF107-YB90M4,WFF107-YDP100M4,WFF107-YDP112M4,WFF107-YDP132M4,WFF107-YDP160M4,WFF107-YDP180M4,WFF107-YDP200M4,WFF107-YDP225M4,WFF107-YDP80M4,WFF107-YDP90M4,WFF107-YE100M4,WFF107-YE112M4,WFF107-YE132M4,WFF107-YE160M4,WFF107-YE180M4,WFF107-YE200M4,WFF107-YE225M4,WFF107-YE80M4,WFF107-YE90M4,WFF107-YEJ100M4,WFF107-YEJ112M4,WFF107-YEJ132M4,WFF107-YEJ160M4,WFF107-YEJ180M4,WFF107-YEJ200M4,WFF107-YEJ225M4,WFF107-YEJ80M4,WFF107-YEJ90M4,WFF107-YEJB100M4,WFF107-YEJB112M4,WFF107-YEJB132M4,WFF107-YEJB160M4,WFF107-YEJB180M4,WFF107-YEJB200M4,WFF107-YEJB225M4,WFF107-YEJB80M4,WFF107-YEJB90M4,WFF107-YP100M4,WFF107-YP112M4,WFF107-YP132M4,WFF107-YP160M4,WFF107-YP180M4,WFF107-YP200M4,WFF107-YP225M4,WFF107-YP80M4,WFF107-YP90M4,WFF107-YPB100M4,WFF107-YPB112M4,WFF107-YPB132M4,WFF107-YPB160M4,WFF107-YPB180M4,WFF107-YPB200M4,WFF107-YPB225M4,WFF107-YPB80M4,WFF107-YPB90M4,WFF107-YPE100M4,WFF107-YPE112M4,WFF107-YPE132M4,WFF107-YPE160M4,WFF107-YPE180M4,WFF107-YPE200M4,WFF107-YPE225M4,WFF107-YPE80M4,WFF107-YPE90M4,WFF107-YS100M4,WFF107-YS112M4,WFF107-YS132M4,WFF107-YS160M4,WFF107-YS180M4,WFF107-YS200M4,WFF107-YS225M4,WFF107-YS80M4,WFF107-YS90M4,WFF107-YVB100M4,WFF107-YVB112M4,WFF107-YVB132M4,WFF107-YVB160M4,WFF107-YVB180M4,WFF107-YVB200M4,WFF107-YVB225M4,WFF107-YVB80M4,WFF107-YVB90M4,WFF107-YVP100M4,WFF107-YVP112M4,WFF107-YVP132M4,WFF107-YVP160M4,WFF107-YVP180M4,WFF107-YVP200M4,WFF107-YVP225M4,WFF107-YVP80M4,WFF107-YVP90M4,WFF107-YVPEJ100M4,WFF107-YVPEJ112M4,WFF107-YVPEJ132M4,WFF107-YVPEJ160M4,WFF107-YVPEJ180M4,WFF107-YVPEJ200M4,WFF107-YVPEJ225M4,WFF107-YVPEJ80M4,WFF107-YVPEJ90M4,AFF107-Y1.5KW,AFF107-Y100M4,AFF107-Y112M4,AFF107-Y11KW,AFF107-Y132M4,AFF107-Y15KW,AFF107-Y160M4,AFF107-Y18.5KW,AFF107-Y180M4,AFF107-Y2.2KW,AFF107-Y200M4,AFF107-Y225M4,AFF107-Y22KW,AFF107-Y30KW,AFF107-Y37KW,AFF107-Y3KW,AFF107-Y45KW,AFF107-Y4KW,AFF107-Y5.5KW,AFF107-Y7.5KW,AFF107-Y80M4,AFF107-Y90M4,AFF107-YB100M4,AFF107-YB112M4,AFF107-YB132M4,AFF107-YB160M4,AFF107-YB180M4,AFF107-YB200M4,AFF107-YB225M4,AFF107-YB80M4,AFF107-YB90M4,AFF107-YDP100M4,AFF107-YDP112M4,AFF107-YDP132M4,AFF107-YDP160M4,AFF107-YDP180M4,AFF107-YDP200M4,AFF107-YDP225M4,AFF107-YDP80M4,AFF107-YDP90M4,AFF107-YE100M4,AFF107-YE112M4,AFF107-YE132M4,AFF107-YE160M4,AFF107-YE180M4,AFF107-YE200M4,AFF107-YE225M4,AFF107-YE80M4,AFF107-YE90M4,AFF107-YEJ100M4,AFF107-YEJ112M4,AFF107-YEJ132M4,AFF107-YEJ160M4,AFF107-YEJ180M4,AFF107-YEJ200M4,AFF107-YEJ225M4,AFF107-YEJ80M4,AFF107-YEJ90M4,AFF107-YEJB100M4,AFF107-YEJB112M4,AFF107-YEJB132M4,AFF107-YEJB160M4,AFF107-YEJB180M4,AFF107-YEJB200M4,AFF107-YEJB225M4,AFF107-YEJB80M4,AFF107-YEJB90M4,AFF107-YP100M4,AFF107-YP112M4,AFF107-YP132M4,AFF107-YP160M4,AFF107-YP180M4,AFF107-YP200M4,AFF107-YP225M4,AFF107-YP80M4,AFF107-YP90M4,AFF107-YPB100M4,AFF107-YPB112M4,AFF107-YPB132M4,AFF107-YPB160M4,AFF107-YPB180M4,AFF107-YPB200M4,AFF107-YPB225M4,AFF107-YPB80M4,AFF107-YPB90M4,AFF107-YPE100M4,AFF107-YPE112M4,AFF107-YPE132M4,AFF107-YPE160M4,AFF107-YPE180M4,AFF107-YPE200M4,AFF107-YPE225M4,AFF107-YPE80M4,AFF107-YPE90M4,AFF107-YS100M4,AFF107-YS112M4,AFF107-YS132M4,AFF107-YS160M4,AFF107-YS180M4,AFF107-YS200M4,AFF107-YS225M4,AFF107-YS80M4,AFF107-YS90M4,AFF107-YVB100M4,AFF107-YVB112M4,AFF107-YVB132M4,AFF107-YVB160M4,AFF107-YVB180M4,AFF107-YVB200M4,AFF107-YVB225M4,AFF107-YVB80M4,AFF107-YVB90M4,AFF107-YVP100M4,AFF107-YVP112M4,AFF107-YVP132M4,AFF107-YVP160M4,AFF107-YVP180M4,AFF107-YVP200M4,AFF107-YVP225M4,AFF107-YVP80M4,AFF107-YVP90M4,AFF107-YVPEJ100M4,AFF107-YVPEJ112M4,AFF107-YVPEJ132M4,AFF107-YVPEJ160M4,AFF107-YVPEJ180M4,AFF107-YVPEJ200M4,AFF107-YVPEJ225M4,AFF107-YVPEJ80M4,AFF107-YVPEJ90M4,GFF109-Y1.5KW,GFF109-Y100M4,GFF109-Y112M4,GFF109-Y11KW,GFF109-Y132M4,GFF109-Y15KW,GFF109-Y160M4,GFF109-Y18.5KW,GFF109-Y180M4,GFF109-Y2.2KW,GFF109-Y200M4,GFF109-Y225M4,GFF109-Y22KW,GFF109-Y30KW,GFF109-Y37KW,GFF109-Y3KW,GFF109-Y45KW,GFF109-Y4KW,GFF109-Y5.5KW,GFF109-Y7.5KW,GFF109-Y80M4,GFF109-Y90M4,GFF109-YB100M4,GFF109-YB112M4,GFF109-YB132M4,GFF109-YB160M4,GFF109-YB180M4,GFF109-YB200M4,GFF109-YB225M4,GFF109-YB80M4,GFF109-YB90M4,GFF109-YDP100M4,GFF109-YDP112M4,GFF109-YDP132M4,GFF109-YDP160M4,GFF109-YDP180M4,GFF109-YDP200M4,GFF109-YDP225M4,GFF109-YDP80M4,GFF109-YDP90M4,GFF109-YE100M4,GFF109-YE112M4,GFF109-YE132M4,GFF109-YE160M4,GFF109-YE180M4,GFF109-YE200M4,GFF109-YE225M4,GFF109-YE80M4,GFF109-YE90M4,GFF109-YEJ100M4,GFF109-YEJ112M4,GFF109-YEJ132M4,GFF109-YEJ160M4,GFF109-YEJ180M4,GFF109-YEJ200M4,GFF109-YEJ225M4,GFF109-YEJ80M4,GFF109-YEJ90M4,GFF109-YEJB100M4,GFF109-YEJB112M4,GFF109-YEJB132M4,GFF109-YEJB160M4,GFF109-YEJB180M4,GFF109-YEJB200M4,GFF109-YEJB225M4,GFF109-YEJB80M4,GFF109-YEJB90M4,GFF109-YP100M4,GFF109-YP112M4,GFF109-YP132M4,GFF109-YP160M4,GFF109-YP180M4,GFF109-YP200M4,GFF109-YP225M4,GFF109-YP80M4,GFF109-YP90M4,GFF109-YPB100M4,GFF109-YPB112M4,GFF109-YPB132M4,GFF109-YPB160M4,GFF109-YPB180M4,GFF109-YPB200M4,GFF109-YPB225M4,GFF109-YPB80M4,GFF109-YPB90M4,GFF109-YPE100M4,GFF109-YPE112M4,GFF109-YPE132M4,GFF109-YPE160M4,GFF109-YPE180M4,GFF109-YPE200M4,GFF109-YPE225M4,GFF109-YPE80M4,GFF109-YPE90M4,GFF109-YS100M4,GFF109-YS112M4,GFF109-YS132M4,GFF109-YS160M4,GFF109-YS180M4,GFF109-YS200M4,GFF109-YS225M4,GFF109-YS80M4,GFF109-YS90M4,GFF109-YVB100M4,GFF109-YVB112M4,GFF109-YVB132M4,GFF109-YVB160M4,GFF109-YVB180M4,GFF109-YVB200M4,GFF109-YVB225M4,GFF109-YVB80M4,GFF109-YVB90M4,GFF109-YVP100M4,GFF109-YVP112M4,GFF109-YVP132M4,GFF109-YVP160M4,GFF109-YVP180M4,GFF109-YVP200M4,GFF109-YVP225M4,GFF109-YVP80M4,GFF109-YVP90M4,GFF109-YVPEJ100M4,GFF109-YVPEJ112M4,GFF109-YVPEJ132M4,GFF109-YVPEJ160M4,GFF109-YVPEJ180M4,GFF109-YVPEJ200M4,GFF109-YVPEJ225M4,GFF109-YVPEJ80M4,GFF109-YVPEJ90M4。
FF109减速机生产厂家展示:看厂请联系微信13827261050,获取位置,需提前一天预约//www.lenable.com/product/list-ffxiliejiansuji-cn.html
推荐类似型号:F109减速机
关键词:带抱闸减速机马达一体机_带刹车电机减速机_FF系列减速器_制动电机减速机_减速器带抱闸_减速机带抱闸_FF系列减速机_FF型减速机_GFF系列减速机_带刹车减速机_带制动减速机_抱闸电机减速机
FF系列齿轮减速电机型号:FF29减速机,FF39减速机,FF49减速机,FF69减速机,FF79减速机,FF89减速机,FF99减速机,FF109减速机,FF129减速机,FF159减速机
FF系列电动机减速机可配变频电机,刹车电机,防爆电机,伺服电机,交流电机,直流电机,三相电机,单相电机 0.12KW-132KW之间
如需工程师帮选型,请加微信13827261050,留言告知工程师参数要求
