KA89R59减速机铭牌参数说明解读含义：有关型号描述的详细情况及其他信息可以参阅本业附件下载中的KA89R59减速机选型样本。

KA89R59-Y0.75KW-4P-562-M1-90°

KA/R：系列代号

89/59：减速机规格代号

Y：电机

0.75KW：电机功率

4P：电机级数

562：减速机传动比

M1：减速机安装位置

90°：接线盒位置

KA89R59减速机电机保养检查：

KA89R59减速机电机一般检查：定期检查电机。检查频率取决于周围空气的潮湿程度以及当地的天气状况。可预先通过试验确定，并严格遵守；保持电机清洁和自然通风。在多灰尘环境中使用电机时必须定期检查通风系统并进行清洁；检查油封的状况，必要时应更换；检查接线和安装螺栓的状况。齿轮减速电机

做一般定期检查时，请需注意：温度上升齿轮减速电机为F级绝缘，全密闭外扇构造，所以电机表面温度比周围高50°C左右即属正常;如果温度高于以上时，必须停机检查（因素：电机或负载传动系统异常）。

KA89R59减速机刹车电机刹车片因长时间使用会有磨损，请依据刹车间隙值进行调整（正常间隙值0.3~0.7mm）。

KA89R59减速机电机异常振动、噪音正常情况，本机几乎没有振动噪音。若有某些安装异常使用，会产生振动噪音，所以请特别留意（当空载噪音值在70dB(A)/1M以下时，是被容许的）；电机通风口有时会积聚杂物妨碍通风，所以请清除电机外部，以确保电机正常运行温度；定期检查时，请用兆欧表以500V测试电机绕组之绝缘阻抗，对地电阻应1MQ以上，以避免漏电之风险。

测定绝缘电阻时，请勿触摸端子。否则有可能会导致触电。减速电机工作时的表面温度较高，请勿赤手触摸。否则有可能会导致烫伤。请勿超出额定负载使用。否则有可能会导致受伤、装置损坏。单相电机的启动用电容器的通电部分，在未完全放电前请勿触及。否则有可能会导致触电。使电机反转时，请务必暂停后开始反转。否则有可能会出现旋转方向未发生改变的电机失控。直角减速机

KA89R59减速机电机不转解决方案：

电源未接通或接触不良或电源电压过低，排查维修；

过载跳闸，选择大容量电机或减轻负载；

机械故障，检查电机和传动装置是否可以自由转动。检查轴承和润滑脂；

电机卡死，更换电机；

电源连接错误，核对接线是否与电机接线图一致；空心轴减速机

定子绕组断路，用万用表欧姆档检查，若有相无电阻，则是此原因，确认后换线圈绕组；

定子绕组匝间短路，用万用表欧姆档检查，若有相电阻与标佳值偏差夭于10%，则是此原因，确认后换线圈绕组；

定子绕组对地短路，用万用表欧姆档检查，若线圈与机壳间有电阻小于1000欧，则是此原因，确认后换线圈绕组；

定子绕组接线错误，拆开电机找出错误，重新接线；

定子线圈的6引线接错，换定子线圈。

KA89R59减速电机型号：

YQKA87RF57-Y0.12KWA，YQKA87R57-Y63M4，YQKA87R57-Y71M4，YQKA87R57-Y80M4，YQKA87R57-Y90M4，YQKA87RF57-Y0.18KWA，YQKA87RF57-Y0.25KWA，YQKA87RF57-Y0.37KWA，YQKA87RF57-Y0.55KWA，YQKA87RF57-Y0.75KWA，YQKA87RF57-Y1.1KWA，YQKA87RF57-Y1.5KWA，YQKA87RF57-Y63M4，YQKA87RF57-Y71M4，YQKA87RF57-Y80M4，YQKA87RF57-Y90M4，YQKA87RF57-YB63M4，YQKA87RF57-YB71M4，YQKA87RF57-YB80M4，YQKA87RF57-YB90S4，YQKA87RF57-YDP63M4，YQKA87RF57-YDP71M4，YQKA87RF57-YDP80M4，YQKA87RF57-YDP90S4，YQKA87RF57-YE63M4，YQKA87RF57-YE71M4，YQKA87RF57-YE80M4，YQKA87RF57-YE90S4，YQKA87RF57-YEJ63M4，YQKA87RF57-YEJ71M4，YQKA87RF57-YEJ80M4，YQKA87RF57-YEJ90S4，YQKA87RF57-YEJB63M4，YQKA87RF57-YEJB71M4，YQKA87RF57-YEJB80M4，YQKA87RF57-YEJB90S4，YQKA87RF57-YP63M4，YQKA87RF57-YP71M4，YQKA87RF57-YP80M4，YQKA87RF57-YP90S4，YQKA87RF57-YPB63M4，YQKA87RF57-YPB71M4，YQKA87RF57-YPB80M4，YQKA87RF57-YPB90S4，YQKA87RF57-YPE63M4，YQKA87RF57-YPE71M4，YQKA87RF57-YPE80M4，YQKA87RF57-YPE90S4，YQKA87RF57-YS63M4，YQKA87RF57-YS71M4，YQKA87RF57-YS80M4，YQKA87RF57-YS90S4，YQKA87RF57-YVB63M4，YQKA87RF57-YVB71M4，YQKA87RF57-YVB80M4，YQKA87RF57-YVB90S4，YQKA87RF57-YVP63M4，YQKA87RF57-YVP71M4，YQKA87RF57-YVP80M4，YQKA87RF57-YVP90S4，YQKA87RF57-YVPEJ63M4，YQKA87RF57-YVPEJ71M4，YQKA87RF57-YVPEJ80M4，YQKA87RF57-YVPEJ90S4，AKA87RF57-Y0.12KWA，AKA87R57-Y63M4，AKA87R57-Y71M4，AKA87R57-Y80M4，AKA87R57-Y90M4，AKA87RF57-Y0.18KWA，AKA87RF57-Y0.25KWA，AKA87RF57-Y0.37KWA，AKA87RF57-Y0.55KWA，AKA87RF57-Y0.75KWA，AKA87RF57-Y1.1KWA，AKA87RF57-Y1.5KWA，AKA87RF57-Y63M4，AKA87RF57-Y71M4，AKA87RF57-Y80M4，AKA87RF57-Y90M4，AKA87RF57-YB63M4，AKA87RF57-YB71M4，AKA87RF57-YB80M4，AKA87RF57-YB90S4，AKA87RF57-YDP63M4，AKA87RF57-YDP71M4，AKA87RF57-YDP80M4，AKA87RF57-YDP90S4，AKA87RF57-YE63M4，AKA87RF57-YE71M4，AKA87RF57-YE80M4，AKA87RF57-YE90S4，AKA87RF57-YEJ63M4，AKA87RF57-YEJ71M4，AKA87RF57-YEJ80M4，AKA87RF57-YEJ90S4，AKA87RF57-YEJB63M4，AKA87RF57-YEJB71M4，AKA87RF57-YEJB80M4，AKA87RF57-YEJB90S4，AKA87RF57-YP63M4，AKA87RF57-YP71M4，AKA87RF57-YP80M4，AKA87RF57-YP90S4，AKA87RF57-YPB63M4，AKA87RF57-YPB71M4，AKA87RF57-YPB80M4，AKA87RF57-YPB90S4，AKA87RF57-YPE63M4，AKA87RF57-YPE71M4，AKA87RF57-YPE80M4，AKA87RF57-YPE90S4，AKA87RF57-YS63M4，AKA87RF57-YS71M4，AKA87RF57-YS80M4，AKA87RF57-YS90S4，AKA87RF57-YVB63M4，AKA87RF57-YVB71M4，AKA87RF57-YVB80M4，AKA87RF57-YVB90S4，AKA87RF57-YVP63M4，AKA87RF57-YVP71M4，AKA87RF57-YVP80M4，AKA87RF57-YVP90S4，AKA87RF57-YVPEJ63M4，AKA87RF57-YVPEJ71M4，AKA87RF57-YVPEJ80M4，AKA87RF57-YVPEJ90S4，SKA87RF57-Y0.12KWA，SKA87R57-Y63M4，SKA87R57-Y71M4，SKA87R57-Y80M4，SKA87R57-Y90M4，SKA87RF57-Y0.18KWA，SKA87RF57-Y0.25KWA，SKA87RF57-Y0.37KWA，SKA87RF57-Y0.55KWA，SKA87RF57-Y0.75KWA，SKA87RF57-Y1.1KWA，SKA87RF57-Y1.5KWA，SKA87RF57-Y63M4，SKA87RF57-Y71M4，SKA87RF57-Y80M4，SKA87RF57-Y90M4，SKA87RF57-YB63M4，SKA87RF57-YB71M4，SKA87RF57-YB80M4，SKA87RF57-YB90S4，SKA87RF57-YDP63M4，SKA87RF57-YDP71M4，SKA87RF57-YDP80M4，SKA87RF57-YDP90S4，SKA87RF57-YE63M4，SKA87RF57-YE71M4，SKA87RF57-YE80M4，SKA87RF57-YE90S4，SKA87RF57-YEJ63M4，SKA87RF57-YEJ71M4，SKA87RF57-YEJ80M4，SKA87RF57-YEJ90S4，SKA87RF57-YEJB63M4，SKA87RF57-YEJB71M4，SKA87RF57-YEJB80M4，SKA87RF57-YEJB90S4，SKA87RF57-YP63M4，SKA87RF57-YP71M4，SKA87RF57-YP80M4，SKA87RF57-YP90S4，SKA87RF57-YPB63M4，SKA87RF57-YPB71M4，SKA87RF57-YPB80M4，SKA87RF57-YPB90S4，SKA87RF57-YPE63M4，SKA87RF57-YPE71M4，SKA87RF57-YPE80M4，SKA87RF57-YPE90S4，SKA87RF57-YS63M4，SKA87RF57-YS71M4，SKA87RF57-YS80M4，SKA87RF57-YS90S4，SKA87RF57-YVB63M4，SKA87RF57-YVB71M4，SKA87RF57-YVB80M4，SKA87RF57-YVB90S4，SKA87RF57-YVP63M4，SKA87RF57-YVP71M4，SKA87RF57-YVP80M4，SKA87RF57-YVP90S4，SKA87RF57-YVPEJ63M4，SKA87RF57-YVPEJ71M4，SKA87RF57-YVPEJ80M4，SKA87RF57-YVPEJ90S4，XDKA87RF57-Y0.12KWA，XDKA87R57-Y63M4，XDKA87R57-Y71M4，XDKA87R57-Y80M4，XDKA87R57-Y90M4，XDKA87RF57-Y0.18KWA，XDKA87RF57-Y0.25KWA，XDKA87RF57-Y0.37KWA，XDKA87RF57-Y0.55KWA，XDKA87RF57-Y0.75KWA，XDKA87RF57-Y1.1KWA，XDKA87RF57-Y1.5KWA，XDKA87RF57-Y63M4，XDKA87RF57-Y71M4，XDKA87RF57-Y80M4，XDKA87RF57-Y90M4，XDKA87RF57-YB63M4，XDKA87RF57-YB71M4，XDKA87RF57-YB80M4，XDKA87RF57-YB90S4，XDKA87RF57-YDP63M4，XDKA87RF57-YDP71M4，XDKA87RF57-YDP80M4，XDKA87RF57-YDP90S4，XDKA87RF57-YE63M4，XDKA87RF57-YE71M4，XDKA87RF57-YE80M4，XDKA87RF57-YE90S4，XDKA87RF57-YEJ63M4，XDKA87RF57-YEJ71M4，XDKA87RF57-YEJ80M4，XDKA87RF57-YEJ90S4，XDKA87RF57-YEJB63M4，XDKA87RF57-YEJB71M4，XDKA87RF57-YEJB80M4，XDKA87RF57-YEJB90S4，XDKA87RF57-YP63M4，XDKA87RF57-YP71M4，XDKA87RF57-YP80M4，XDKA87RF57-YP90S4，XDKA87RF57-YPB63M4，XDKA87RF57-YPB71M4，XDKA87RF57-YPB80M4，XDKA87RF57-YPB90S4，XDKA87RF57-YPE63M4，XDKA87RF57-YPE71M4，XDKA87RF57-YPE80M4，XDKA87RF57-YPE90S4，XDKA87RF57-YS63M4，XDKA87RF57-YS71M4，XDKA87RF57-YS80M4，XDKA87RF57-YS90S4，XDKA87RF57-YVB63M4，XDKA87RF57-YVB71M4，XDKA87RF57-YVB80M4，XDKA87RF57-YVB90S4，XDKA87RF57-YVP63M4，XDKA87RF57-YVP71M4，XDKA87RF57-YVP80M4，XDKA87RF57-YVP90S4，XDKA87RF57-YVPEJ63M4，XDKA87RF57-YVPEJ71M4，XDKA87RF57-YVPEJ80M4，XDKA87RF57-YVPEJ90S4，WKA87RF57-Y0.12KWA，WKA87R57-Y63M4，WKA87R57-Y71M4，WKA87R57-Y80M4，WKA87R57-Y90M4，WKA87RF57-Y0.18KWA，WKA87RF57-Y0.25KWA，WKA87RF57-Y0.37KWA，WKA87RF57-Y0.55KWA，WKA87RF57-Y0.75KWA，WKA87RF57-Y1.1KWA，WKA87RF57-Y1.5KWA，WKA87RF57-Y63M4，WKA87RF57-Y71M4，WKA87RF57-Y80M4，WKA87RF57-Y90M4，WKA87RF57-YB63M4，WKA87RF57-YB71M4，WKA87RF57-YB80M4，WKA87RF57-YB90S4，WKA87RF57-YDP63M4，WKA87RF57-YDP71M4，WKA87RF57-YDP80M4，WKA87RF57-YDP90S4，WKA87RF57-YE63M4，WKA87RF57-YE71M4，WKA87RF57-YE80M4，WKA87RF57-YE90S4，WKA87RF57-YEJ63M4，WKA87RF57-YEJ71M4，WKA87RF57-YEJ80M4，WKA87RF57-YEJ90S4，WKA87RF57-YEJB63M4，WKA87RF57-YEJB71M4，WKA87RF57-YEJB80M4，WKA87RF57-YEJB90S4，WKA87RF57-YP63M4，WKA87RF57-YP71M4，WKA87RF57-YP80M4，WKA87RF57-YP90S4，WKA87RF57-YPB63M4，WKA87RF57-YPB71M4，WKA87RF57-YPB80M4，WKA87RF57-YPB90S4，WKA87RF57-YPE63M4，WKA87RF57-YPE71M4，WKA87RF57-YPE80M4，WKA87RF57-YPE90S4，WKA87RF57-YS63M4，WKA87RF57-YS71M4，WKA87RF57-YS80M4，WKA87RF57-YS90S4，WKA87RF57-YVB63M4，WKA87RF57-YVB71M4，WKA87RF57-YVB80M4，WKA87RF57-YVB90S4，WKA87RF57-YVP63M4，WKA87RF57-YVP71M4，WKA87RF57-YVP80M4，WKA87RF57-YVP90S4，WKA87RF57-YVPEJ63M4，WKA87RF57-YVPEJ71M4，WKA87RF57-YVPEJ80M4，WKA87RF57-YVPEJ90S4，JCKA87RF57-Y0.12KWA，JCKA87R57-Y63M4，JCKA87R57-Y71M4，JCKA87R57-Y80M4，JCKA87R57-Y90M4，JCKA87RF57-Y0.18KWA，JCKA87RF57-Y0.25KWA，JCKA87RF57-Y0.37KWA，JCKA87RF57-Y0.55KWA，JCKA87RF57-Y0.75KWA，JCKA87RF57-Y1.1KWA，JCKA87RF57-Y1.5KWA，JCKA87RF57-Y63M4，JCKA87RF57-Y71M4，JCKA87RF57-Y80M4，JCKA87RF57-Y90M4，JCKA87RF57-YB63M4，JCKA87RF57-YB71M4，JCKA87RF57-YB80M4，JCKA87RF57-YB90S4，JCKA87RF57-YDP63M4，JCKA87RF57-YDP71M4，JCKA87RF57-YDP80M4，JCKA87RF57-YDP90S4，JCKA87RF57-YE63M4，JCKA87RF57-YE71M4，JCKA87RF57-YE80M4，JCKA87RF57-YE90S4，JCKA87RF57-YEJ63M4，JCKA87RF57-YEJ71M4，JCKA87RF57-YEJ80M4，JCKA87RF57-YEJ90S4，JCKA87RF57-YEJB63M4，JCKA87RF57-YEJB71M4，JCKA87RF57-YEJB80M4，JCKA87RF57-YEJB90S4，JCKA87RF57-YP63M4，JCKA87RF57-YP71M4，JCKA87RF57-YP80M4，JCKA87RF57-YP90S4，JCKA87RF57-YPB63M4，JCKA87RF57-YPB71M4，JCKA87RF57-YPB80M4，JCKA87RF57-YPB90S4，JCKA87RF57-YPE63M4，JCKA87RF57-YPE71M4，JCKA87RF57-YPE80M4，JCKA87RF57-YPE90S4，JCKA87RF57-YS63M4，JCKA87RF57-YS71M4，JCKA87RF57-YS80M4，JCKA87RF57-YS90S4，JCKA87RF57-YVB63M4，JCKA87RF57-YVB71M4，JCKA87RF57-YVB80M4，JCKA87RF57-YVB90S4，JCKA87RF57-YVP63M4，JCKA87RF57-YVP71M4，JCKA87RF57-YVP80M4，JCKA87RF57-YVP90S4，JCKA87RF57-YVPEJ63M4，JCKA87RF57-YVPEJ71M4，JCKA87RF57-YVPEJ80M4，JCKA87RF57-YVPEJ90S4，NKA87RF57-Y0.12KWA，NKA87R57-Y63M4，NKA87R57-Y71M4，NKA87R57-Y80M4，NKA87R57-Y90M4，NKA87RF57-Y0.18KWA，NKA87RF57-Y0.25KWA，NKA87RF57-Y0.37KWA，NKA87RF57-Y0.55KWA，NKA87RF57-Y0.75KWA，NKA87RF57-Y1.1KWA，NKA87RF57-Y1.5KWA，NKA87RF57-Y63M4，NKA87RF57-Y71M4，NKA87RF57-Y80M4，NKA87RF57-Y90M4，NKA87RF57-YB63M4，NKA87RF57-YB71M4，NKA87RF57-YB80M4，NKA87RF57-YB90S4，NKA87RF57-YDP63M4，NKA87RF57-YDP71M4，NKA87RF57-YDP80M4，NKA87RF57-YDP90S4，NKA87RF57-YE63M4，NKA87RF57-YE71M4，NKA87RF57-YE80M4，NKA87RF57-YE90S4，NKA87RF57-YEJ63M4，NKA87RF57-YEJ71M4，NKA87RF57-YEJ80M4，NKA87RF57-YEJ90S4，NKA87RF57-YEJB63M4，NKA87RF57-YEJB71M4，NKA87RF57-YEJB80M4，NKA87RF57-YEJB90S4，NKA87RF57-YP63M4，NKA87RF57-YP71M4，NKA87RF57-YP80M4，NKA87RF57-YP90S4，NKA87RF57-YPB63M4，NKA87RF57-YPB71M4，NKA87RF57-YPB80M4，NKA87RF57-YPB90S4，NKA87RF57-YPE63M4，NKA87RF57-YPE71M4，NKA87RF57-YPE80M4，NKA87RF57-YPE90S4，NKA87RF57-YS63M4，NKA87RF57-YS71M4，NKA87RF57-YS80M4，NKA87RF57-YS90S4，NKA87RF57-YVB63M4，NKA87RF57-YVB71M4，NKA87RF57-YVB80M4，NKA87RF57-YVB90S4，NKA87RF57-YVP63M4，NKA87RF57-YVP71M4，NKA87RF57-YVP80M4，NKA87RF57-YVP90S4，NKA87RF57-YVPEJ63M4，NKA87RF57-YVPEJ71M4，NKA87RF57-YVPEJ80M4，NKA87RF57-YVPEJ90S4，KWA87RWF57-Y0.12KWA，KWA87RW57-Y63M4，KWA87RW57-Y71M4，KWA87RW57-Y80M4，KWA87RW57-Y90M4，KWA87RWF57-Y0.18KWA，KWA87RWF57-Y0.25KWA，KWA87RWF57-Y0.37KWA，KWA87RWF57-Y0.55KWA，KWA87RWF57-Y0.75KWA，KWA87RWF57-Y1.1KWA，KWA87RWF57-Y1.5KWA，KWA87RWF57-Y63M4，KWA87RWF57-Y71M4，KWA87RWF57-Y80M4，KWA87RWF57-Y90M4，KWA87RWF57-YB63M4，KWA87RWF57-YB71M4，KWA87RWF57-YB80M4，KWA87RWF57-YB90S4，KWA87RWF57-YDP63M4，KWA87RWF57-YDP71M4，KWA87RWF57-YDP80M4，KWA87RWF57-YDP90S4，KWA87RWF57-YE63M4，KWA87RWF57-YE71M4，KWA87RWF57-YE80M4，KWA87RWF57-YE90S4，KWA87RWF57-YEJ63M4，KWA87RWF57-YEJ71M4，KWA87RWF57-YEJ80M4，KWA87RWF57-YEJ90S4，KWA87RWF57-YEJB63M4，KWA87RWF57-YEJB71M4，KWA87RWF57-YEJB80M4，KWA87RWF57-YEJB90S4，KWA87RWF57-YP63M4，KWA87RWF57-YP71M4，KWA87RWF57-YP80M4，KWA87RWF57-YP90S4，KWA87RWF57-YPB63M4，KWA87RWF57-YPB71M4，KWA87RWF57-YPB80M4，KWA87RWF57-YPB90S4，KWA87RWF57-YPE63M4，KWA87RWF57-YPE71M4，KWA87RWF57-YPE80M4，KWA87RWF57-YPE90S4，KWA87RWF57-YS63M4，KWA87RWF57-YS71M4，KWA87RWF57-YS80M4，KWA87RWF57-YS90S4，KWA87RWF57-YVB63M4，KWA87RWF57-YVB71M4，KWA87RWF57-YVB80M4，KWA87RWF57-YVB90S4，KWA87RWF57-YVP63M4，KWA87RWF57-YVP71M4，KWA87RWF57-YVP80M4，KWA87RWF57-YVP90S4，KWA87RWF57-YVPEJ63M4，KWA87RWF57-YVPEJ71M4，KWA87RWF57-YVPEJ80M4，KWA87RWF57-YVPEJ90S4，KA89RF59-Y0.12KWA，KA89R59-Y63M4，KA89R59-Y71M4，KA89R59-Y80M4，KA89R59-Y90M4，KA89RF59-Y0.18KWA，KA89RF59-Y0.25KWA，KA89RF59-Y0.37KWA，KA89RF59-Y0.55KWA，KA89RF59-Y0.75KWA，KA89RF59-Y1.1KWA，KA89RF59-Y1.5KWA，KA89RF59-Y63M4，KA89RF59-Y71M4，KA89RF59-Y80M4，KA89RF59-Y90M4，KA89RF59-YB63M4，KA89RF59-YB71M4，KA89RF59-YB80M4，KA89RF59-YB90S4，KA89RF59-YDP63M4，KA89RF59-YDP71M4，KA89RF59-YDP80M4，KA89RF59-YDP90S4，KA89RF59-YE63M4，KA89RF59-YE71M4，KA89RF59-YE80M4，KA89RF59-YE90S4，KA89RF59-YEJ63M4，KA89RF59-YEJ71M4，KA89RF59-YEJ80M4，KA89RF59-YEJ90S4，KA89RF59-YEJB63M4，KA89RF59-YEJB71M4，KA89RF59-YEJB80M4，KA89RF59-YEJB90S4，KA89RF59-YP63M4，KA89RF59-YP71M4，KA89RF59-YP80M4，KA89RF59-YP90S4，KA89RF59-YPB63M4，KA89RF59-YPB71M4，KA89RF59-YPB80M4，KA89RF59-YPB90S4，KA89RF59-YPE63M4，KA89RF59-YPE71M4，KA89RF59-YPE80M4，KA89RF59-YPE90S4，KA89RF59-YS63M4，KA89RF59-YS71M4，KA89RF59-YS80M4，KA89RF59-YS90S4，KA89RF59-YVB63M4，KA89RF59-YVB71M4，KA89RF59-YVB80M4，KA89RF59-YVB90S4，KA89RF59-YVP63M4，KA89RF59-YVP71M4，KA89RF59-YVP80M4，KA89RF59-YVP90S4，KA89RF59-YVPEJ63M4，KA89RF59-YVPEJ71M4，KA89RF59-YVPEJ80M4，KA89RF59-YVPEJ90S4。
