网站首页 > BOSERL减速机 > 同轴斜齿轮减速电机 > RF系列齿轮减速电机

RF59减速机详细信息

prevnext

RF59减速机

订购热线:13360667204
  1. 详细信息

RF59减速机铭牌参数说明解读含义:有关型号描述的详细情况及其他信息可以参阅本业附件下载中的RF59减速机选型样本。

RF59-BVP132M4-7.97-M2-180°

RF:系列代号

59:减速机规格代号

B:电机

VP:变频电机

132:电机规格代号

M:电机定子铁心长度代号

4:电机级数

7.97:减速机传动比

M2:减速机安装位置

180°:接线盒位置


RF59减速机润滑油型号:

RF59减速机特殊应用场合必须使用特殊润滑油,比如要求长使用寿命润滑油。若需要可提供用于食品行业和生物降解润滑油。

RF59减速机润滑油加注量,具体值根据级数与传动比的不同而各异。请您在加注润滑油时一定注意油位螺栓所指示的精确油量。本页附件中的RF59减速机选型样本中列出了安装位置从M1到M6RF59减速机相应的润滑油加注标准,请自行下载查看。

RF59减速机某些安装位置发生搅油损失的机会较高。出现下列情况时请与BOSERL公司进行联系:若无特殊规定,BOSERL公司发货时会根据RF59减速机的安装位置给驱动装置加润滑油,因此应在订货时指定安装位置(M1…M6,参见“RF59减速机说明书中的安装位置与订货说明”章节)。若之后对安装位置需要改动,则加润滑油必须与安装位置相符(润滑油加注量)。RF系列减速机

RF59减速机推荐使用的润滑油,其等级和粘度指标见下表:

ISO标准润滑油

粘贴指标

环境温度°C

减速机型号

MINERALOILCLP(cc)

ISOVG220

-10-+40

R系列、F系列、K系列减速机

ISOVG680

0-+40

S系列减速机

ISO标准润滑油

粘贴指标

环境温度°C

减速机型号

MINERALOILCLP(cc)

ISOVG100

-20-+25

R系列、F系列、K系列减速机

Synthetic fluid,clp pg

ISOVG220

-25-+80

R系列、F系列、K系列减速机

Synthetic fluid,CLP HC

ISOVG460

-30-+80

S系列减速机

R - 副本 - 副本 - 副本.jpg

RF59减速机使用说明:

RF59减速机的螺母:立式安装RF59减速机输出法兰直径160螺母规格M8;立式安装RF59减速机输出法兰直径250螺母规格M12;RF59减速机螺母/螺母拧紧扭矩强度等级10.9。齿轮减速电机

RF59减速机危险使用说明:驱动装置意外启动会造成挤伤,可能造成重伤或死亡;开始工作前,应先断开减速电机的电源并且采取措施防止意外接通!

RF59减速机警告说明:由于RF59减速机发热或RF59减速机油温过高可能引起烫伤;对RF59减速机进行操作前先冷却;拧出油位检查螺栓和放油螺栓时要格外小心。

RF59减速机注意事项:若未注入正确的RF59减速机油则可能造成润滑油性能失效,可能造成财产损失;合成润滑油不可能相互混用并不可与矿物润滑油混用;矿物油用作标准的润滑油,不能用于特殊行业。

RF59减速机提示事项:油位检查螺栓、放油螺栓、以及透气阀的位置在安装位置上,要参见RF59减速机说明书安装位置章节中的内容。立式减速机

RF59减速机型号:

YQRF57-AM100M4,YQRF57-AM112M4,YQRF57-AM132M4,YQRF57-AM63M4,YQRF57-AM71M4,YQRF57-AM80M4,YQRF57-AM90M4,YQRF57-Y0.12KW,YQRF57-Y0.18KW,YQRF57-Y0.25KW,YQRF57-Y0.37KW,YQRF57-Y0.55KW,YQRF57-Y0.75KW,YQRF57-Y1.1KW,YQRF57-Y1.5KW,YQRF57-Y100M4,YQRF57-Y112M4,YQRF57-Y132M4,YQRF57-Y2.2KW,YQRF57-Y3KW,YQRF57-Y4KW,YQRF57-Y5.5KW,YQRF57-Y63M4,YQRF57-Y7.5KW,YQRF57-Y71M4,YQRF57-Y80M4,YQRF57-Y90M4,YQRF57-YB100M4,YQRF57-YB112M4,YQRF57-YB132M4,YQRF57-YB63M4,YQRF57-YB71M4,YQRF57-YB80M4,YQRF57-YB90M4,YQRF57-YDP100M4,YQRF57-YDP112M4,YQRF57-YDP132M4,YQRF57-YDP63M4,YQRF57-YDP71M4,YQRF57-YDP80M4,YQRF57-YDP90M4,YQRF57-YE100M4,YQRF57-YE112M4,YQRF57-YE132M4,YQRF57-YE63M4,YQRF57-YE71M4,YQRF57-YE80M4,YQRF57-YE90M4,YQRF57-YEJ100M4,YQRF57-YEJ112M4,YQRF57-YEJ132M4,YQRF57-YEJ63M4,YQRF57-YEJ71M4,YQRF57-YEJ80M4,YQRF57-YEJ90M4,YQRF57-YEJB100M4,YQRF57-YEJB112M4,YQRF57-YEJB132M4,YQRF57-YEJB63M4,YQRF57-YEJB71M4,YQRF57-YEJB80M4,YQRF57-YEJB90M4,YQRF57-YP100M4,YQRF57-YP112M4,YQRF57-YP132M4,YQRF57-YP63M4,YQRF57-YP71M4,YQRF57-YP80M4,YQRF57-YP90M4,YQRF57-YPB100M4,YQRF57-YPB112M4,YQRF57-YPB132M4,YQRF57-YPB63M4,YQRF57-YPB71M4,YQRF57-YPB80M4,YQRF57-YPB90M4,YQRF57-YPE100M4,YQRF57-YPE112M4,YQRF57-YPE132M4,YQRF57-YPE63M4,YQRF57-YPE71M4,YQRF57-YPE80M4,YQRF57-YPE90M4,YQRF57-YS100M4,YQRF57-YS112M4,YQRF57-YS132M4,YQRF57-YS63M4,YQRF57-YS71M4,YQRF57-YS80M4,YQRF57-YS90M4,YQRF57-YVB100M4,YQRF57-YVB112M4,YQRF57-YVB132M4,YQRF57-YVB63M4,YQRF57-YVB71M4,YQRF57-YVB80M4,YQRF57-YVB90M4,YQRF57-YVP100M4,YQRF57-YVP112M4,YQRF57-YVP132M4,YQRF57-YVP63M4,YQRF57-YVP71M4,YQRF57-YVP80M4,YQRF57-YVP90M4,YQRF57-YVPEJ100M4,YQRF57-YVPEJ112M4,YQRF57-YVPEJ132M4,YQRF57-YVPEJ63M4,YQRF57-YVPEJ71M4,YQRF57-YVPEJ80M4,YQRF57-YVPEJ90M4,JCRF57-AM100M4,JCRF57-AM112M4,JCRF57-AM132M4,JCRF57-AM63M4,JCRF57-AM71M4,JCRF57-AM80M4,JCRF57-AM90M4,JCRF57-Y0.12KW,JCRF57-Y0.18KW,JCRF57-Y0.25KW,JCRF57-Y0.37KW,JCRF57-Y0.55KW,JCRF57-Y0.75KW,JCRF57-Y1.1KW,JCRF57-Y1.5KW,JCRF57-Y100M4,JCRF57-Y112M4,JCRF57-Y132M4,JCRF57-Y2.2KW,JCRF57-Y3KW,JCRF57-Y4KW,JCRF57-Y5.5KW,JCRF57-Y63M4,JCRF57-Y7.5KW,JCRF57-Y71M4,JCRF57-Y80M4,JCRF57-Y90M4,JCRF57-YB100M4,JCRF57-YB112M4,JCRF57-YB132M4,JCRF57-YB63M4,JCRF57-YB71M4,JCRF57-YB80M4,JCRF57-YB90M4,JCRF57-YDP100M4,JCRF57-YDP112M4,JCRF57-YDP132M4,JCRF57-YDP63M4,JCRF57-YDP71M4,JCRF57-YDP80M4,JCRF57-YDP90M4,JCRF57-YE100M4,JCRF57-YE112M4,JCRF57-YE132M4,JCRF57-YE63M4,JCRF57-YE71M4,JCRF57-YE80M4,JCRF57-YE90M4,JCRF57-YEJ100M4,JCRF57-YEJ112M4,JCRF57-YEJ132M4,JCRF57-YEJ63M4,JCRF57-YEJ71M4,JCRF57-YEJ80M4,JCRF57-YEJ90M4,JCRF57-YEJB100M4,JCRF57-YEJB112M4,JCRF57-YEJB132M4,JCRF57-YEJB63M4,JCRF57-YEJB71M4,JCRF57-YEJB80M4,JCRF57-YEJB90M4,JCRF57-YP100M4,JCRF57-YP112M4,JCRF57-YP132M4,JCRF57-YP63M4,JCRF57-YP71M4,JCRF57-YP80M4,JCRF57-YP90M4,JCRF57-YPB100M4,JCRF57-YPB112M4,JCRF57-YPB132M4,JCRF57-YPB63M4,JCRF57-YPB71M4,JCRF57-YPB80M4,JCRF57-YPB90M4,JCRF57-YPE100M4,JCRF57-YPE112M4,JCRF57-YPE132M4,JCRF57-YPE63M4,JCRF57-YPE71M4,JCRF57-YPE80M4,JCRF57-YPE90M4,JCRF57-YS100M4,JCRF57-YS112M4,JCRF57-YS132M4,JCRF57-YS63M4,JCRF57-YS71M4,JCRF57-YS80M4,JCRF57-YS90M4,JCRF57-YVB100M4,JCRF57-YVB112M4,JCRF57-YVB132M4,JCRF57-YVB63M4,JCRF57-YVB71M4,JCRF57-YVB80M4,JCRF57-YVB90M4,JCRF57-YVP100M4,JCRF57-YVP112M4,JCRF57-YVP132M4,JCRF57-YVP63M4,JCRF57-YVP71M4,JCRF57-YVP80M4,JCRF57-YVP90M4,JCRF57-YVPEJ100M4,JCRF57-YVPEJ112M4,JCRF57-YVPEJ132M4,JCRF57-YVPEJ63M4,JCRF57-YVPEJ71M4,JCRF57-YVPEJ80M4,JCRF57-YVPEJ90M4,XDRF57-AM100M4,XDRF57-AM112M4,XDRF57-AM132M4,XDRF57-AM63M4,XDRF57-AM71M4,XDRF57-AM80M4,XDRF57-AM90M4,XDRF57-Y0.12KW,XDRF57-Y0.18KW,XDRF57-Y0.25KW,XDRF57-Y0.37KW,XDRF57-Y0.55KW,XDRF57-Y0.75KW,XDRF57-Y1.1KW,XDRF57-Y1.5KW,XDRF57-Y100M4,XDRF57-Y112M4,XDRF57-Y132M4,XDRF57-Y2.2KW,XDRF57-Y3KW,XDRF57-Y4KW,XDRF57-Y5.5KW,XDRF57-Y63M4,XDRF57-Y7.5KW,XDRF57-Y71M4,XDRF57-Y80M4,XDRF57-Y90M4,XDRF57-YB100M4,XDRF57-YB112M4,XDRF57-YB132M4,XDRF57-YB63M4,XDRF57-YB71M4,XDRF57-YB80M4,XDRF57-YB90M4,XDRF57-YDP100M4,XDRF57-YDP112M4,XDRF57-YDP132M4,XDRF57-YDP63M4,XDRF57-YDP71M4,XDRF57-YDP80M4,XDRF57-YDP90M4,XDRF57-YE100M4,XDRF57-YE112M4,XDRF57-YE132M4,XDRF57-YE63M4,XDRF57-YE71M4,XDRF57-YE80M4,XDRF57-YE90M4,XDRF57-YEJ100M4,XDRF57-YEJ112M4,XDRF57-YEJ132M4,XDRF57-YEJ63M4,XDRF57-YEJ71M4,XDRF57-YEJ80M4,XDRF57-YEJ90M4,XDRF57-YEJB100M4,XDRF57-YEJB112M4,XDRF57-YEJB132M4,XDRF57-YEJB63M4,XDRF57-YEJB71M4,XDRF57-YEJB80M4,XDRF57-YEJB90M4,XDRF57-YP100M4,XDRF57-YP112M4,XDRF57-YP132M4,XDRF57-YP63M4,XDRF57-YP71M4,XDRF57-YP80M4,XDRF57-YP90M4,XDRF57-YPB100M4,XDRF57-YPB112M4,XDRF57-YPB132M4,XDRF57-YPB63M4,XDRF57-YPB71M4,XDRF57-YPB80M4,XDRF57-YPB90M4,XDRF57-YPE100M4,XDRF57-YPE112M4,XDRF57-YPE132M4,XDRF57-YPE63M4,XDRF57-YPE71M4,XDRF57-YPE80M4,XDRF57-YPE90M4,XDRF57-YS100M4,XDRF57-YS112M4,XDRF57-YS132M4,XDRF57-YS63M4,XDRF57-YS71M4,XDRF57-YS80M4,XDRF57-YS90M4,XDRF57-YVB100M4,XDRF57-YVB112M4,XDRF57-YVB132M4,XDRF57-YVB63M4,XDRF57-YVB71M4,XDRF57-YVB80M4,XDRF57-YVB90M4,XDRF57-YVP100M4,XDRF57-YVP112M4,XDRF57-YVP132M4,XDRF57-YVP63M4,XDRF57-YVP71M4,XDRF57-YVP80M4,XDRF57-YVP90M4,XDRF57-YVPEJ100M4,XDRF57-YVPEJ112M4,XDRF57-YVPEJ132M4,XDRF57-YVPEJ63M4,XDRF57-YVPEJ71M4,XDRF57-YVPEJ80M4,XDRF57-YVPEJ90M4,RF59-AM100M4,RF59-AM112M4,RF59-AM132M4,RF59-AM63M4,RF59-AM71M4,RF59-AM80M4,RF59-AM90M4,RF59-Y0.12KW,RF59-Y0.18KW,RF59-Y0.25KW,RF59-Y0.37KW,RF59-Y0.55KW,RF59-Y0.75KW,RF59-Y1.1KW,RF59-Y1.5KW,RF59-Y100M4,RF59-Y112M4,RF59-Y132M4,RF59-Y2.2KW,RF59-Y3KW,RF59-Y4KW,RF59-Y5.5KW,RF59-Y63M4,RF59-Y7.5KW,RF59-Y71M4,RF59-Y80M4,RF59-Y90M4,RF59-YB100M4,RF59-YB112M4,RF59-YB132M4,RF59-YB63M4,RF59-YB71M4,RF59-YB80M4,RF59-YB90M4,RF59-YDP100M4,RF59-YDP112M4,RF59-YDP132M4,RF59-YDP63M4,RF59-YDP71M4,RF59-YDP80M4,RF59-YDP90M4,RF59-YE100M4,RF59-YE112M4,RF59-YE132M4,RF59-YE63M4,RF59-YE71M4,RF59-YE80M4,RF59-YE90M4,RF59-YEJ100M4,RF59-YEJ112M4,RF59-YEJ132M4,RF59-YEJ63M4,RF59-YEJ71M4,RF59-YEJ80M4,RF59-YEJ90M4,RF59-YEJB100M4,RF59-YEJB112M4,RF59-YEJB132M4,RF59-YEJB63M4,RF59-YEJB71M4,RF59-YEJB80M4,RF59-YEJB90M4,RF59-YP100M4,RF59-YP112M4,RF59-YP132M4,RF59-YP63M4,RF59-YP71M4,RF59-YP80M4,RF59-YP90M4,RF59-YPB100M4,RF59-YPB112M4,RF59-YPB132M4,RF59-YPB63M4,RF59-YPB71M4,RF59-YPB80M4,RF59-YPB90M4,RF59-YPE100M4,RF59-YPE112M4,RF59-YPE132M4,RF59-YPE63M4,RF59-YPE71M4,RF59-YPE80M4,RF59-YPE90M4,RF59-YS100M4,RF59-YS112M4,RF59-YS132M4,RF59-YS63M4,RF59-YS71M4,RF59-YS80M4,RF59-YS90M4,RF59-YVB100M4,RF59-YVB112M4,RF59-YVB132M4,RF59-YVB63M4,RF59-YVB71M4,RF59-YVB80M4,RF59-YVB90M4,RF59-YVP100M4,RF59-YVP112M4,RF59-YVP132M4,RF59-YVP63M4,RF59-YVP71M4,RF59-YVP80M4,RF59-YVP90M4,RF59-YVPEJ100M4,RF59-YVPEJ112M4,RF59-YVPEJ132M4,RF59-YVPEJ63M4,RF59-YVPEJ71M4,RF59-YVPEJ80M4,RF59-YVPEJ90M4,RWF57-AM100M4,RWF57-AM112M4,RWF57-AM132M4,RWF57-AM63M4,RWF57-AM71M4,RWF57-AM80M4,RWF57-AM90M4,RWF57-Y0.12KW,RWF57-Y0.18KW,RWF57-Y0.25KW,RWF57-Y0.37KW,RWF57-Y0.55KW,RWF57-Y0.75KW,RWF57-Y1.1KW,RWF57-Y1.5KW,RWF57-Y100M4,RWF57-Y112M4,RWF57-Y132M4,RWF57-Y2.2KW,RWF57-Y3KW,RWF57-Y4KW,RWF57-Y5.5KW,RWF57-Y63M4,RWF57-Y7.5KW,RWF57-Y71M4,RWF57-Y80M4,RWF57-Y90M4,RWF57-YB100M4,RWF57-YB112M4,RWF57-YB132M4,RWF57-YB63M4,RWF57-YB71M4,RWF57-YB80M4,RWF57-YB90M4,RWF57-YDP100M4,RWF57-YDP112M4,RWF57-YDP132M4,RWF57-YDP63M4,RWF57-YDP71M4,RWF57-YDP80M4,RWF57-YDP90M4,RWF57-YE100M4,RWF57-YE112M4,RWF57-YE132M4,RWF57-YE63M4,RWF57-YE71M4,RWF57-YE80M4,RWF57-YE90M4,RWF57-YEJ100M4,RWF57-YEJ112M4,RWF57-YEJ132M4,RWF57-YEJ63M4,RWF57-YEJ71M4,RWF57-YEJ80M4,RWF57-YEJ90M4,RWF57-YEJB100M4,RWF57-YEJB112M4,RWF57-YEJB132M4,RWF57-YEJB63M4,RWF57-YEJB71M4,RWF57-YEJB80M4,RWF57-YEJB90M4,RWF57-YP100M4,RWF57-YP112M4,RWF57-YP132M4,RWF57-YP63M4,RWF57-YP71M4,RWF57-YP80M4,RWF57-YP90M4,RWF57-YPB100M4,RWF57-YPB112M4,RWF57-YPB132M4,RWF57-YPB63M4,RWF57-YPB71M4,RWF57-YPB80M4,RWF57-YPB90M4,RWF57-YPE100M4,RWF57-YPE112M4,RWF57-YPE132M4,RWF57-YPE63M4,RWF57-YPE71M4,RWF57-YPE80M4,RWF57-YPE90M4,RWF57-YS100M4,RWF57-YS112M4,RWF57-YS132M4,RWF57-YS63M4,RWF57-YS71M4,RWF57-YS80M4,RWF57-YS90M4,RWF57-YVB100M4,RWF57-YVB112M4,RWF57-YVB132M4,RWF57-YVB63M4,RWF57-YVB71M4,RWF57-YVB80M4,RWF57-YVB90M4,RWF57-YVP100M4,RWF57-YVP112M4,RWF57-YVP132M4,RWF57-YVP63M4,RWF57-YVP71M4,RWF57-YVP80M4,RWF57-YVP90M4,RWF57-YVPEJ100M4,RWF57-YVPEJ112M4,RWF57-YVPEJ132M4,RWF57-YVPEJ63M4,RWF57-YVPEJ71M4,RWF57-YVPEJ80M4,RWF57-YVPEJ90M4。

RF59减速机生产厂家展示:看厂请联系微信13827261050,获取位置,需提前一天预约//www.lenable.com/product/list-rfxiliejiansuji-cn.html

齿轮减速电机一体机

齿轮减速电机一体机

齿轮减速电机一体机

齿轮减速电机一体机

推荐类似型号:R59减速机

关键词:直连电机带减速机立式一体机_直线输出减速机_RF系列减速器_直连减速机_直连减速器_直联减速机_GRF系列减速机_RF系列减速机_RF型减速机_RF齿轮减速电机

RF系列减速机型号:RF19减速机,RF29减速机,RF39减速机,RF49减速机,RF59减速机,RF69减速机,RF79减速机,RF89减速机,RF99减速机,RF109减速机,RF139减速机,RF149减速机,RF169减速机

RF系列斜齿轮减速机可配变频电机,刹车电机,防爆电机,伺服电机,交流电机,直流电机,三相电机,单相电机 0.12KW-132KW之间

如需工程师帮选型,请加微信13827261050,留言告知工程师参数要求


标签:   RF59减速机 RF57减速机结构图 RF57减速机数模 RF57减速机样本 RF57减速机规格

跟此产品相关的文档 / Related DownLoad

产品文件名称 点击下载
RF59减速机三维图纸下载3D 点击下载
RF59减速机选型样本 点击下载
